Eaton Warranty+3 Product 04, Distributed services (Electronic format), Eaton Warranty extension for 3 years - W3004WEB

Nationwide Onsite Maintenance is as easy as saying Bronze, Silver, Gold, Platinum.

1: Plug and Play (400VA-3kVA) – Extended Warranty Contracts and Maintenance contracts

For plug & play UPS Critical Power offers you a full range of distributed service packs. These competitively priced turn-key solutions optimize your UPS performances and enhance the availability of your equipment while meeting your financial constraints and technical requirements.

Warranty Plus Extends your standard warranty up to 6 years, next working day replacement* with labour or without.
Intervention, Provides one preventative maintenance visit, planned visit inside our outside hours.
Battery Plus, Provides replacement batteries to site, next working day replacement or same day

2: Hardwired (4kVA Upwards including Three Phase UPS) – Maintenance Contracts

No matter what, your UPS, Generator, Cooling, Switchgear or Electrical Hardware must be ready to perform at all times. While every power solution we supply is backed-up by a comprehensive warranty with the manufacturer, maintenance plans to ensure business continuity are highly recommended, particularly for UPS systems from 4kVA. In particular, the battery set is of prime importance, and must be in good working order. With other consumables, such as fans and DC capacitors requiring regular maintenance and inspection logs reviewed to predict potential future problems.

Services Included	Silver Level	Gold Level	Platinum Level	Platinum Plus
Technical Hotline 24/7	Yes	Yes	Yes	Yes
Preventative Maintenance	Yes	Yes	Yes	Yes
Remote Monitoring 24/7	Yes	Yes	Yes	Yes
Firmware Upgrades	Yes	Yes	Yes	Yes
Emergency Response	Yes	Yes	Yes	Yes
Labour	Yes	Yes	Yes	Yes
Parts	Yes	Yes	Yes	option
Monthly Event/Status Report	option	option	option	option
Onsite Crash Kit	option	option	option	onsite
Response Time	12 working hours	8 working hours	4 clock hours	4 clock hours
Guaranteed Fix time	–	–	–	4 Clock hours

3: 24×7 Remote Monitoring Contracts –

Remote monitoring of UPS, Generators, Air Conditioning, Site Access and Environmental Systems is essential to allow swift offsite investigation of fault reports and real-time monitoring of the site status, allowing the correct response to be created and dispatched to site.

Engineer Installation and configuration during normal hours
24×7 flexible status and remote monitoring.
Encrypted communication, allowing safe offsite monitoring
Alarms and events emailed and SMS texted automatically
Firewall Friendly
Cloud based status overview and multiple sites status on one screen
Allows First Fix Response to Site

4. IR Thermal Imaging Surveys – Infrared electrical inspection. Infrared electrical testing finds hot, dangerous problems quickly. Infrared electrical inspections find hot spots caused by defects in connections and components. – Contact us for more information.

Detect system overloads, loose defective components and damaged switchgear. Infrared electrical testing finds hot, dangerous problems quickly. Infrared electrical inspections find hot spots caused by defects in connections and components.

Infrared thermography is used to find areas of excess heat (caused by increased resistance) so that problems can be corrected before a component fails, causing damage to the component, creating safety hazards and productivity loss. Because increased heating is a sign of failure, infrared is the best diagnostic tool available for finding these hot connections in the early stages of degeneration.

5. Switchgear – Contact us for more information.

Switchgear maintenance is essential for efficient save plant operation and prolonged life span in the field Switchgear should be maintained as follows.

• Live Maintenance – Unintrusive and consists of taking metering values, carrying out visual inspections and a thermal imaging survey of the switchboard. This is recommended to be carried out yearly.
• Breaker Maintenance – Switchboard would need to be Isolated and all ACB’s and MCCB’s are maintained including visual and mechanical checks, greasing and secondary injection testing of the trip units. This is recommended to be carried out every 2 years.
• Full Isolated Maintenance – Switchboard would need to be fully isolated from upstream supplies (HV). Breakers are maintained as per the above but also full maintenance carried out of the Switchboard to clean all compartments and carry out tightness checking of busbars and terminations etc. This is recommended to be carried out every 4 years.
